Place of Origin:
China
Brand Name:
OEM
Certification:
CE, UN38.3, MSDS
Model Number:
LFP24-100
50AH 100AH Lithium LiFePO4 Rack Mount Battery Wholesale
25.6V 100AH Lifepo4 Battery Pack, lifepo4 battery pack supplier
Smart LFP series LiFePO4 battery is a high-tech product developed for the requirements of new backup power supply and household renewable energy storage. Built-in intelligent BMS to protect the battery pack at any time and prolong its service life, modular design enables parallel installation for larger power back up. All of our batteries use A grade cells, can communicate with mainstream inverter brands.
1. High Capacity
2. Long Cycle Life
3. High Discharge Rate
4. High Safety and Reliability
5. Lightweight and Compact
| MODEL # | LFP 24-100 | LFP 48-50 | LFP 48-100 |
| SPECIFICATION | |||
| Battery Type | LiFePO4 | LiFePO4 | LiFePO4 |
| Battery Model | 25.6V100AH | 51.2V50AH | 51.2V100AH |
| Nominal Capacity(25℃,0.2C)WH | 2560Wh | 2560Wh | 5120Wh |
| Adjustable working voltage(Vdc) | 22.4～29.2V | 44.8～58.4V | 44.8～58.4V |
| Folat Charge Voltage(Vdc) | 28V | 56V | 56V |
| Max.Continuous discharge current(A) | 100 | 100 | 100 |
| Max.pulse discharge current(A) | 150A 1Sec. | 100A 1Sec. | 150A 1Sec. |
| Max.Continuous charge current(A) | 100 | 50 | 100 |
| Cycle life(+25℃ 0.2C 80% DOD) | ＞5000 Cycles | ＞5000 Cycles | ＞5000 Cycles |
| Cell Equalizer Current(A | 0.1～5A Max.(optional) | 0.1～5A Max.(optional) | 0.1～5A Max.(optional) |
| Terminal | M6 | ||
| Storage duration | 6 months at 25℃ | ||
| Safety standard | IEC62619,UN38.3,MSDS,CE | ||
| Communication function | RS484/UART/SNMP/Wifi/Bluetooth | ||
| PROTECTION | |||
| Protection | Overcharge protectionOverdischarge protectionOvercurrent protection Shortcircuit protectionOvertemperature protection | ||
| AMBIENT | |||
| Noise(dB) | ＜40dB(1 meter) | ||
| Working temperature | -20℃～+60℃ | ||
| Humidity | 0～95%(no condensation) | ||
| Altitude(m) | <3000 | ||
| DIMENSION | |||
| L*W*H( size)mm | L405*W483*H178mm | L655*W483*H178mm | |
| L*W*H(package size)mm | L440*W518*H213mm | L690*W518*H213mm | |
| Net Weight(Kg): | Approx.35kg | Approx.72kg | |
| Gross Weight(Kg): | Approx.39kg | Approx.78kg | |
We offer technical support and services for LiFePO4 Battery Pack, including:
1). Are the batteries GRADE-A,Brand NEW?
Yes, GRADE A + quality. the QR code is intact, Brand new.
2). Are the batteries come with busbars+bolts?
The price come with Bus bars and Bolts , One Battery will come with one set bus bar and bolt ( e.g.,lf buy 4pcs battery,we will send 4pcs cells with 4pcs busbars and 8pcs bolts ) If need more please contact us online.
3).Can you test each battery PRIOR to shipping?
We will test all the battery Voltage and Internal resistance before shipping.
4.) What kind of the package of the cells?
Pack with strong package, each cell into thickness PE foam or bag, then into 5 layers strong carton.
