Place of Origin:
China
Brand Name:
G-tech
Certification:
CE/RoHS/ISO
Model Number:
MP
MP Series 3000W model 3024,Solar Power Off-grid Pure Sine Wave Home Inverter,AC/Solar Input
Specification:
| Model | 3024 | |||
| Real power | 3000W | |||
| AC MODE | ||||
| Input Voltage | 160~265 ± 5 Vac | |||
|
Input Frequency |
45-65Hz | |||
| Output Voltage | 160~265 ± 5 Vac | |||
| Efficiency | ≥96%(AC mode) | |||
| Inverter mode | ||||
|
No load current & power |
1A/24 W | |||
| THD | <3% (linear load) | |||
| Output Voltage | 230Vac | |||
| Output Frequency | 50 ± 0.1Hz/60± 0.1Hz(Auto sensing) | |||
|
Output Wave form |
Pure sine wave | |||
| Tranfer time | < 10ms | |||
| Efficiency | ≥80% (battery mode) | |||
|
Overload Capability |
(100%<load<120%) ±10%:Auto shutdown in 2 mins (120%<load<140%) ±10%:Auto shutdown in 60 secs; (140%<load) ±10%:Auto shutdown in 20 secs |
|||
| Overcurrent Protection | System shuts down automatically within 20ms | |||
| Output short circuit protection | Yes | |||
| Battery | ||||
| DC voltage | 24V | |||
| Battery type | 8 types of battery | |||
| AC charging current | 5A/10A/20A/30A/45A(60A)Max | |||
| Physical | ||||
| Net weight(kg) | 27.1 | |||
| Dimention(mm) 526(L)*277(W)*215(H)mm | ||||
| Enviroment | Temperature 0℃~40℃,Humidity 20%~90% | |||
| Noisy level | ≤ 40dB(1m) | |||
| Altitude | ≤ 1000m(Altitude exceeds 1000m, full power cannot reach) | |||
Product specifications are subject to change without notice.
